Description
The Procon Pump NSF Brass 80 GPH 3/8″ NPT w/ .188″ Double Flat Drive (Clamp-on) Series 2 Rotary Vane Pump is a positive displacement pump. This Series 2 Procon pump is brass and includes a .188″ Double Flat Drive. The inlet and outlet ports are 3/8″ NPT and the pump has a flow-rate of 80 gallons per hour. The elastometer and seal configuration for this pump is high-quality Nitrile Type 21, which will prevent leakage. The clockwise rotation of the pump operates at a nominal speed of 1725 rotations per minute. The Series 2 pumps are self-priming, so there is virtually no maintenance. The maximum discharge pressure for this pump is 250 PSI. The 112B125F11XX pump is designed to be directly connected to the motor with a stainless steel clamp.
Specifications:
- NSF Standard 169 listed
- Capacity: 80 GPH
- Nominal Speed: 1725 RPM
- Maximum Discharge Pressure: 250 PSI
- Rotation: Clockwise
- Self-priming & maintenance free
- Port Size: 3/8″ NPT Inlet and Outlet
- .188″ Double Flat Drive
Typical Applications:
- Carbonation
- Espresso & coffee
- Welding
- Cold carb circulation
- Reverse osmosis
- Beer chillers
- Pesticide Systems
- Solar Applications
