Description
Features:
- Machined from high quality acrylic, polished to a clear finish
- Annealed for added strength and chemical resistance
- Acceptable for outdoor installations (direct sunlight okay)
- Designed for in-line installation
- Easy to read scale
Neo-Pure Compatibles For Blue White
.catalog a{ text-decoration: none; color: #24a7bd; transition: ease, 0.3s; cursor: pointer; } .catalog a:hover{ color: #2276c5; } .catalog h3{ text-align: left; text-transform: uppercase; font-size: 16px; font-weight: 900; font-family: Jost, sans-serif; letter-spacing: 0.1em; padding: 40px 0px 20px; color: rgb(80, 81, 79); border-bottom: 1px solid rgb(225, 225, 225); margin-top: 20px; margin-bottom: 20px; cursor: default; }
Inline Flow Meters
| Flow Rate | Connection | Blue White | Neo-Pure |
|---|---|---|---|
| 0.1-1.0 GPM | 1/2″ FPT | F-40375LN-8 | FMS1-011-08 |
| 0.2-2.0 GPM | 1/2″ FPT | F-40376LN-8 | FMS1-022-08 |
| 0.5-5.0 GPM | 1/2″ FPT | F-40500LN-8 | FMS1-055-08 |
| 2.0-20 GPM | 3/4″ FPT | F-41000LN-12 | FMS1-220-16 |
| 2.0-20 GPM | 1″ FPT | F-41000LN-16 | FMS1-220-16 |
| 2.0-20 GPM | 1″ FPT | F-451002LHN | FMS1-220-16 |
| 3.0-30 GPM | 1″ FPT | F-451003LHN | FMS1-530-16 |
Panel Mounted Flow Meters
| Flow Rate | Connection | Blue White | Neo-Pure |
|---|---|---|---|
| 0.2-20 GPM | 1″ MPT | F-55200L* | FMP0-216-16* |
| 0.2-2.0 GPM | 3/8″ MPT | F-55376L | FMP0-022-06 |
| 0.5-5.0 GPM | 1/2″ MPT | F-55500L | FMP0-055-08 |
| 0.1-10 GPM | 3/4″ MPT | F-55750L | FMP0-210-12 |
Adjustable Panel Mounted Flow Meters
| Flow Rate | Connection | Blue White | Neo-Pure |
|---|---|---|---|
| 0.2-20 GPM | 1″ MPT | F-55200LA** | FMP1-216-16** |
| 0.1-1.0 GPM | 3/8″ MPT | F-55375LA*** | FMP1-011-04*** |
| 0.2-2.0 GPM | 3/8″ MPT | F-55376LA | FMP1-022-06 |
| 0.5-5.0 GPM | 1/2″ MPT | F-55500LA | FMP1-055-08 |
| 0.1-10 GPM | 3/4″ MPT | F-55750LA | FMP1-210-12 |
Please note: While all Neo-Pure listed are direct replacements for Blue White, the following panel mounted flowmeters differ in mounting spread.
Blue White:
F-55200L* – 8 inch
F-55200LA** – 8 inch
F-55375LA*** – 6.5 inch
Neo-Pure:
FMP0-216-16* – 6.5 inch
FMP1-216-16** – 6.5 inch
FMP1-011-04*** – 5 inch
